Novafiber
1 / 5
| Item | RJ45 Female Connector |
| Compatible With | 0854-2X8R-GK-F |
| Part Status | Active |
| Connector Type | Jack |
| Number of Positions/Contacts | 8p8c (RJ45, Ethernet) |
| Application-Lan | Ethernet(NoN PoE) |
| Number of Ports | 2x8 Port |
| Speed | 10/100/1000 Base-T |
| Latch | Down/Up |
| Cores per Port | 4 |
| Orientation | 90° Angle (Right) |
| PCB Mount Angle | SIDE ENTRY |
| Shield EMI Tabs | Without/With |
| LED Option | Green/Yellow |
| PCB | FR4 |
| PCB Retaining Post | T POST |
| Temperature | 0°C TO 70°C / -40°C TO 85°C |
| Bst Circuit | Yes |
| AutomDX | YES |
| Contact Mating Area Plating | GOLD 6u"/15u"/30u" |
| Turns Ratio RX/TX | 1CT:1CT |
| Configuration RX/TX | T,C |
❓1. Are you factory or trading company?
We are a specialized manufacturer of magnetic telecom and networking components, such as RJ45 connectors, LAN transformers, RJ11 connectors, and SFP modules.
❓2. Can I get a sample before mass production?
Yes, we can offer you free samples to test quality, with shipping costs covered by the buyer.
❓3. What is your delivery time?
Items in stock are ready to ship, and mass production typically takes 15-30 days.
❓4. What after-service can you offer?
We provide a one-year guarantee period along with 24-hour online technical support.
❓5. Can you accept OEM/ODM orders?
Yes, please contact us with your specifications so we can discuss your requirements in detail.
❓6. What is your advantage?
We bring 19 years of professional production experience and have served as a trusted partner to major global technology integrators for many years.
